What A Remote Management System Does
Keeps CCTV cameras powered from solar and battery backup
Switches between solar and a 48V supply automatically, using solar first during the day
Powers seven 12V cameras or devices and one 48V device
Lets you switch outputs on and off remotely, and pulse an output to reset a camera that has frozen
Sheds non-essential loads when the battery runs low, so critical cameras stay up
Sends alerts for tampering and low battery
Reports voltage, current, power, temperature and network health to a cloud platform
Protects every output against over-current, short circuits and overheating
RMS-330
The RMS-330 is the standard controller. It charges at up to 25A and suits sites running a 12V battery up to 100Ah.
| Charger | 330W, maximum charge 25A at 14.5V, 93% efficiency |
|---|---|
| Inputs | 2 x surge-protected inputs (50V maximum) for solar or a 48V AC/DC converter |
| Maximum input current | 20A |
| Minimum solar input voltage | 18V |
| Outputs | 7 x 12V 3A solid-state outputs with over-current and over-temperature protection |
| 48V output | 1 x 48V 2A boost converter, fuse protected |
| Maximum discharge power | 348W |
| Power use with no load | 4.5W |
| Battery | up to 100Ah 12V |
| Battery cables | 1.3m, 10mm² with 10mm ring lugs fitted |
| Connections | 1 x Ethernet port, 2 x digital inputs |
| Sensors | anti-tamper sensors and an internal temperature sensor |
| Cooling | automatic forced-air cooling |
| Operating temperature | minus 30°C to 65°C ambient |
| Enclosure | powder-coated sheet metal and anodised aluminium |
| Weight | 3kg (controller only) |
| Warranty | 24 months when bought outright, or 3 years with an MX-Tech maintenance contract |
RMS-660
The RMS-660 does the same job as the RMS-330 with twice the charging power. It charges at up to 50A, takes a battery up to 200Ah, and adds an accelerometer that detects impact and tilt, so you know if a pole is being pulled down.
| Charger | 660W, maximum charge 50A at 14.5V, 93% efficiency |
|---|---|
| Inputs | 2 x surge-protected inputs (50V maximum) for solar or a 48V AC/DC converter |
| Maximum input current | 20A |
| Solar input voltage | 18V minimum, 50V maximum |
| Outputs | 7 x 12V 3A solid-state outputs with over-current and over-temperature protection |
| 12V output efficiency | 99.2% |
| 48V output | 1 x 48V 2A boost converter, fuse protected |
| Maximum discharge power | 348W |
| Power use with no load | 4.5W |
| AC frequency range | 46 to 65Hz |
| Battery | up to 200Ah 12.8V |
| Battery types | all lead acid and rechargeable lithium chemistries |
| Battery charging | programmable 3-stage: bulk, peak, absorption, then float |
| Battery cables | 1.3m, 10mm² with 10mm ring lugs fitted |
| Connections | 1 x Ethernet port (RJ45 10/100), 2 x opto-isolated digital inputs (5 to 24V DC) |
| Sensors | anti-tamper sensors, a programmable accelerometer for impact and tilt, and an internal temperature sensor |
| Remote firmware upgrade | yes |
| Cooling | automatic forced-air cooling |
| Operating temperature | minus 30°C to 65°C ambient |
| Operating humidity | 55% normal, 95% non-condensing available on request as a coastal specification |
| Enclosure | powder-coated sheet metal and anodised aluminium |
| Dimensions | 285 x 86 x 190mm |
| Weight | 3kg (controller only) |
| Warranty | 24 months when bought outright, or 3 years with an MX-Tech maintenance contract |
Which Model Do I Need?
| Specification | RMS-330 | RMS-660 |
|---|---|---|
| Charger | 330W | 660W |
| Maximum charge current | 25A at 14.5V | 50A at 14.5V |
| Battery | up to 100Ah 12V | up to 200Ah 12.8V |
| 12V outputs | 7 x 3A | 7 x 3A |
| 48V output | 1 x 2A | 1 x 2A |
| Impact and tilt detection | No | Yes |
| Warranty | 24 months | 24 months |
Both units run on the same cloud platform and are installed by the same team. The RMS-660 is the one to choose when the site has more cameras, a bigger battery, or a pole that needs watching.
RMS Questions
Can CCTV cameras run on solar power?
Yes. A Remote Management System charges a battery from solar panels during the day and powers the cameras from the battery at night and in bad weather.
What is the difference between the RMS-330 and the RMS-660?
The RMS-660 has a 660W charger against the RMS-330’s 330W, so it charges at up to 50A instead of 25A. It also takes a battery up to 200Ah rather than 100Ah, and it adds impact and tilt detection. Everything else, including the outputs and the cloud platform, is the same.
Does it work with 12V and 48V cameras?
Yes. Both models have seven 12V outputs and one 48V output.
What alerts does it send?
Both send alerts when someone tampers with the unit and when the battery runs low. The RMS-660 also reports impact and tilt. Power and battery data is available on the cloud platform, and the service includes daily reports by WhatsApp.
Can I reset a camera remotely?
Yes. Each 12V output can be switched off and on, or pulsed, from the cloud platform. That resets a camera that has stopped responding without sending anyone to site.
Can I rent it instead of buying?
Yes. Both models are available as a monthly service as well as an outright purchase.
Who installs it?
MX-Tech installs the RMS-330 and the RMS-660, and offers maintenance contracts.
