Insele Solar Remote Management Systems

Solar Power Management For Remote CCTV

A Remote Management System is a smart power controller for CCTV cameras at sites with no reliable mains supply. It charges a battery from solar panels or a 48V supply, powers both 12V and 48V cameras, and sends power and battery data to a secure cloud platform over Ethernet. If someone tampers with the unit or the battery runs low, you get an alert. That makes it practical for companies looking after many camera sites at once.

There are two models. The RMS-330 is the standard unit. The RMS-660 charges twice as fast, takes a bigger battery and adds impact and tilt detection. You can buy either outright or take it as a monthly service. MX-Tech installs and maintains the systems.

  • 12V & 48V
  • Cloud Monitoring
  • Tamper Alerts

12-month warranty from Microtronix Manufacturing · Designed and made in Johannesburg

What A Remote Management System Does

Keeps CCTV cameras powered from solar and battery backup

Switches between solar and a 48V supply automatically, using solar first during the day

Powers seven 12V cameras or devices and one 48V device

Lets you switch outputs on and off remotely, and pulse an output to reset a camera that has frozen

Sheds non-essential loads when the battery runs low, so critical cameras stay up

Sends alerts for tampering and low battery

Reports voltage, current, power, temperature and network health to a cloud platform

Protects every output against over-current, short circuits and overheating

Insele Solar RMS System

RMS-330

The RMS-330 is the standard controller. It charges at up to 25A and suits sites running a 12V battery up to 100Ah.

Insele Solar RMS-330 Remote Management System For Remote CCTV

Charger 330W, maximum charge 25A at 14.5V, 93% efficiency
Inputs 2 x surge-protected inputs (50V maximum) for solar or a 48V AC/DC converter
Maximum input current 20A
Minimum solar input voltage 18V
Outputs 7 x 12V 3A solid-state outputs with over-current and over-temperature protection
48V output 1 x 48V 2A boost converter, fuse protected
Maximum discharge power 348W
Power use with no load 4.5W
Battery up to 100Ah 12V
Battery cables 1.3m, 10mm² with 10mm ring lugs fitted
Connections 1 x Ethernet port, 2 x digital inputs
Sensors anti-tamper sensors and an internal temperature sensor
Cooling automatic forced-air cooling
Operating temperature minus 30°C to 65°C ambient
Enclosure powder-coated sheet metal and anodised aluminium
Weight 3kg (controller only)
Warranty 24 months when bought outright, or 3 years with an MX-Tech maintenance contract

RMS-660

The RMS-660 does the same job as the RMS-330 with twice the charging power. It charges at up to 50A, takes a battery up to 200Ah, and adds an accelerometer that detects impact and tilt, so you know if a pole is being pulled down.

Insele Solar RMS-660 Remote Management System For Remote CCTV

Charger 660W, maximum charge 50A at 14.5V, 93% efficiency
Inputs 2 x surge-protected inputs (50V maximum) for solar or a 48V AC/DC converter
Maximum input current 20A
Solar input voltage 18V minimum, 50V maximum
Outputs 7 x 12V 3A solid-state outputs with over-current and over-temperature protection
12V output efficiency 99.2%
48V output 1 x 48V 2A boost converter, fuse protected
Maximum discharge power 348W
Power use with no load 4.5W
AC frequency range 46 to 65Hz
Battery up to 200Ah 12.8V
Battery types all lead acid and rechargeable lithium chemistries
Battery charging programmable 3-stage: bulk, peak, absorption, then float
Battery cables 1.3m, 10mm² with 10mm ring lugs fitted
Connections 1 x Ethernet port (RJ45 10/100), 2 x opto-isolated digital inputs (5 to 24V DC)
Sensors anti-tamper sensors, a programmable accelerometer for impact and tilt, and an internal temperature sensor
Remote firmware upgrade yes
Cooling automatic forced-air cooling
Operating temperature minus 30°C to 65°C ambient
Operating humidity 55% normal, 95% non-condensing available on request as a coastal specification
Enclosure powder-coated sheet metal and anodised aluminium
Dimensions 285 x 86 x 190mm
Weight 3kg (controller only)
Warranty 24 months when bought outright, or 3 years with an MX-Tech maintenance contract

Which Model Do I Need?

Specification RMS-330 RMS-660
Charger 330W 660W
Maximum charge current 25A at 14.5V 50A at 14.5V
Battery up to 100Ah 12V up to 200Ah 12.8V
12V outputs 7 x 3A 7 x 3A
48V output 1 x 2A 1 x 2A
Impact and tilt detection No Yes
Warranty 24 months 24 months

Both units run on the same cloud platform and are installed by the same team. The RMS-660 is the one to choose when the site has more cameras, a bigger battery, or a pole that needs watching.

RMS Questions

Can CCTV cameras run on solar power?

Yes. A Remote Management System charges a battery from solar panels during the day and powers the cameras from the battery at night and in bad weather.

What is the difference between the RMS-330 and the RMS-660?

The RMS-660 has a 660W charger against the RMS-330’s 330W, so it charges at up to 50A instead of 25A. It also takes a battery up to 200Ah rather than 100Ah, and it adds impact and tilt detection. Everything else, including the outputs and the cloud platform, is the same.

Does it work with 12V and 48V cameras?

Yes. Both models have seven 12V outputs and one 48V output.

What alerts does it send?

Both send alerts when someone tampers with the unit and when the battery runs low. The RMS-660 also reports impact and tilt. Power and battery data is available on the cloud platform, and the service includes daily reports by WhatsApp.

Can I reset a camera remotely?

Yes. Each 12V output can be switched off and on, or pulsed, from the cloud platform. That resets a camera that has stopped responding without sending anyone to site.

Can I rent it instead of buying?

Yes. Both models are available as a monthly service as well as an outright purchase.

Who installs it?

MX-Tech installs the RMS-330 and the RMS-660, and offers maintenance contracts.
